Running Multiple Java Apps with Different JDK Versions on the Same Server

Because not every team migrates to Java 21 at the same pace

You've got six microservices. Three run on Java 17. Two are stuck on Java 11 (legacy vendor SDK, don't ask). One brave soul upgraded to Java 21. Management says: "Run them all on one box to save costs."

Here's how to do it without losing your mind.

The Problem

By default, Linux has one java in your PATH. Running java -jar app.jar uses whatever that default is. If your apps need different versions, you're stuck.

The fix: Don't rely on the system default. Point each app to its specific Java binary.

Step 1: Install Multiple Java Versions

Ubuntu/Debian

apt update apt install -y openjdk-11-jre-headless \ openjdk-17-jre-headless \ openjdk-21-jre-headless

Amazon Linux / RHEL

yum install -y java-11-amazon-corretto-headless \ java-17-amazon-corretto-headless \ java-21-amazon-corretto-headless

Verify Installation

# List installed versions update-java-alternatives --list # Debian/Ubuntu # Or find them manually ls -la /usr/lib/jvm/

Typical Paths

Step 2: Create Systemd Services with Explicit Java Paths

The key: Use absolute paths to the Java binary. Don't rely on JAVA_HOME or system defaults.

App 1: Legacy service on Java 11

# /etc/systemd/system/legacy-api.service [Unit] Description=Legacy API (Java 11) After=network.target [Service] User=appuser WorkingDirectory=/opt/apps/legacy-api ExecStart=/usr/lib/jvm/java-11-openjdk-amd64/bin/java \ -Xms256m -Xmx512m \ -XX:+UseG1GC \ -jar /opt/apps/legacy-api/legacy-api.jar Restart=always RestartSec=5 [Install] WantedBy=multi-user.target

App 2: Main service on Java 17

# /etc/systemd/system/main-api.service [Unit] Description=Main API (Java 17) After=network.target [Service] User=appuser WorkingDirectory=/opt/apps/main-api ExecStart=/usr/lib/jvm/java-17-openjdk-amd64/bin/java \ -Xms512m -Xmx1g \ -XX:+UseG1GC \ -jar /opt/apps/main-api/main-api.jar Restart=always RestartSec=5 [Install] WantedBy=multi-user.target

App 3: New service on Java 21

# /etc/systemd/system/new-api.service [Unit] Description=New API (Java 21) After=network.target [Service] User=appuser WorkingDirectory=/opt/apps/new-api ExecStart=/usr/lib/jvm/java-21-openjdk-amd64/bin/java \ -Xms512m -Xmx1g \ -XX:+UseZGC \ -XX:+ZGenerational \ -jar /opt/apps/new-api/new-api.jar Restart=always RestartSec=5 [Install] WantedBy=multi-user.target

Step 3: Enable and Start

systemctl daemon-reload systemctl enable --now legacy-api main-api new-api # Verify each is using correct version systemctl status legacy-api systemctl status main-api systemctl status new-api

A Cleaner Pattern for Multiple Apps

If you're managing many services, use environment files to keep things DRY.

Create an environment file per app

# /opt/apps/main-api/.env JAVA_HOME=/usr/lib/jvm/java-17-openjdk-amd64 JAVA_OPTS=-Xms512m -Xmx1g -XX:+UseG1GC APP_PORT=8080

Reference it in the service file

[Service] EnvironmentFile=/opt/apps/main-api/.env ExecStart=/bin/bash -c 'exec $JAVA_HOME/bin/java $JAVA_OPTS -Dserver.port=$APP_PORT -jar /opt/apps/main-api/main-api.jar' Restart=always RestartSec=5 [Install] WantedBy=multi-user.target

Why the bash -c wrapper? Systemd doesn't expand variables in ExecStart the way a shell does. The bash wrapper handles that.

Memory Planning Matters

Running multiple JVMs on one machine requires careful memory allocation. JVMs consume more than just heap — they use metaspace, thread stacks, and native memory.

A rough planning guide for a t3.large (8 GB RAM):

OS reserved: ~1 GB legacy-api: -Xmx512m main-api: -Xmx1g new-api: -Xmx1g worker-1: -Xmx512m worker-2: -Xmx512m scheduler: -Xmx256m ------------------------------ Total: ~3.8 GB heap + ~2 GB metaspace/overhead Free: ~1-2 GB buffer

Leave headroom. JVMs use more than just heap (metaspace, thread stacks, native memory).

Quick Reference

The Takeaway

Running multiple Java versions on one server isn't complicated:

1. Install all versions via package manager
2. Use absolute paths in systemd services
3. Never rely on system defaults
4. Plan your memory budget

The trick isn't technical wizardry — it's being explicit about which Java runs which app.

Have a different approach? Running into edge cases? Drop a comment — I'd like to hear how others solve this.
